Description
Rock Solid. Light Weight.
Now featuring laser-engraved metal sight tapes!
FEATURES
SIGHT SCALE PLATES
MAGNIFIER COMPATIBLE
The Scale Magnifier mounts to the flat shelf indicator’s groove, enabling higher precision elevation adjustments than ever.
(sold separately)
ZPE SYSTEM【Patent pending】
ULTIMA CPX sights feature a revolutionary system eliminating backlash and play in the elevation adjustments: the ZPE system. A readjustable aluminum wedge, secured with Nord-Lock® washers, eliminates any gap between the threaded locking block and aperture block.
FLAT SHELF INDICATOR PIN
The new flat-shelf indicator pin on ULTIMA CPX sights is easy to adjust, closer to the sight tape surface than ever before, while still offering enough clearance for layered tapes. Both side pins are locked by a cap screw from the side, preventing accidental movements when locking them down!
TRIA-LOCK SYSTEM
Shibuya’s innovative Tria-Lock system keeps the scope rod approx. 1/2″ closer to the elevation bar than conventional target sights. This significantly reduces moment effected on the windage unit – a significant factor in development of play and faults!
The innovative new Tria-Lock system encloses the scope rod holder from three sides, keeping it perfectly aligned and without play to produce a rattle-free, zero-tolerance environment.
X-Lock System US Pat No. 7,287,335
Re-adjustable, zero-tolerance fit between the windage unit and sight frame. Super-slick and durable polyacetal resin guide spacers enclose the elevation rail, re-adjustable at the turn of a set screw. All parts field-adjustable and -replaceable!
